Specifications:
Â
(Note: Night videos are limited to a maximum of 30 seconds to conserve the batteries. If set video length higher than 30 seconds, e.g. 60 seconds, the max recording length at night keeps 30 seconds.)
Working Mode |
Motion detection or Time Lapse |
Max. Pixel Size |
24MP |
Lens |
F=2.0, FOV=110°, Auto IR-Cut |
IR Flash |
70ft |
LCD Screen |
2.4" Color screen |
Keypad |
6 Keys, 1 Power switch |
Memory |
SD, SDHC or SDXC Regular memory card (Not included), max capacity 512GB |
Picture Resolution |
24MP, 20MP, 16MP, 8MP, 4MP, 2MP |
Video Resolution |
1296P@20fps 16:9, 1080P@30fps 16:9, 720P@30fps 16:9 |
Video Format |
MP4/MOV |
Video Compression |
H.264 |
PIR Sensitivity |
High/Normal/Low |
PIR Sensing Distance |
75ft (Below 77°F/25°C) |
PIR Sensing Angle |
70° |
Trigger Time |
Approx. 0.3 second |
Trigger Interval |
0sec.-60min, Programmable |
Shooting Numbers |
1~5 |
Video Length |
3sec ~ 5min., Programmable (Note: Max 30 seconds at night time to conserve batteries lifetime) |
Info Strip |
On /Off |
Operation Hours |
On /Off, Specific working period of time |
Password |
4-Digit Code |
Camera Name |
4-Character (A-Z, 0-9) |
Time Lapse |
1 Sec. ~ 24 Hours |
Power Supply |
8x1.5V AA Batteries Or External 12V Power Supply with 4.0x1.7mm plug (Not included) |
Stand-by Time |
8 Months |
Auto Stand-by |
Auto Stand-by (Surveillance mode) in 5 minutes while no operation in SET mode |
Low Battery Alarm |
8V - Low Battery (Batteries die) 9V - Night vision is unavailable in low voltage(Almost die) |
Interface |
Mini-USB, Regular SD card holder, External Power (DC 12V/1A, Plug 4.0x1.7mm) |
Mounting |
 Strap, Tripod Base (1/4-20) |
Waterproof |
IP66 |
Operation Temperature |
-4~140°F/-20~60°C |
Operation Humidity |
5% ~ 95% |
Certificate |
FCC & CE & RoHS |
Product Dimensions |
6.1 x 4.4 x 3.0 inches |
For more details, please click to download the camera manual.
NOTE:
The power time depends on the quality of batteries. If you take or record many pictures/videos in a short time, the power will fall out quickly.
